Eight-conductor shielded cables for complex multi-circuit applications
RVVP 8-core shielded cables are engineered for the most demanding applications requiring multiple independent circuits with superior EMI protection. Featuring eight distinct color-coded conductors and tinned copper braided shielding, these cables ensure interference-free signal transmission in complex industrial environments.
With exceptional flexibility and durability, our RVVP 8-core cables provide reliable performance in automation systems, control panels, and multi-circuit applications where precision and reliability are critical.
| Model | Conductor Structure | Insulation Thickness (mm) | Shielding Coverage | Sheath Thickness (mm) | Avg. Diameter (mm) | Conductor Resistance (Ω/km) |
|---|---|---|---|---|---|---|
| RVVP 8×0.5 | 16/0.2 | 0.6 | ≥85% | 0.8 | 8.5 | ≤39.0 |
| RVVP 8×1.0 | 32/0.2 | 0.6 | ≥85% | 0.8 | 10.5 | ≤19.5 |
| RVVP 8×1.5 | 30/0.25 | 0.7 | ≥85% | 1.0 | 12.0 | ≤13.3 |
Note: Standard colors: Brown, Black, Grey, Blue, White, Pink, Yellow, Green/Yellow. Custom colors available upon request. All products undergo rigorous quality control testing to ensure compliance with international standards. Specifications may vary slightly based on manufacturing standards.
