CAT6 SFTP Outdoor cable delivers 1Gbps speeds with 250MHz bandwidth, featuring double-layer shielding and weatherproof construction for reliable EMI protection and durability in harsh outdoor environments.
Weatherproof shielded networking solution designed for harsh outdoor environments with superior EMI protection.
| Specification | Value |
|---|---|
| Category | CAT6 SFTP Outdoor |
| Conductor Material | 100% Oxygen-Free Copper (OFC) |
| Conductor Size | 23 AWG (0.57mm) |
| Shielding | SFTP (Screened Foiled Twisted Pair) |
| Jacket Material | PE (Polyethylene) - UV Resistant |
| Cable Diameter | 6.5mm |
| Color Options | Black, Gray |
| Parameter | Value |
|---|---|
| Bandwidth | 250 MHz |
| Data Transfer Rate | Up to 1 Gbps |
| Max Distance | 100 meters (328 feet) |
| Impedance | 100Ω ±15% |
| Propagation Delay | ≤ 548 ns/100m |
| Feature | Specification |
|---|---|
| Connector Type | RJ45 (8P8C) |
| Contact Plating | 50μ" Gold Plating |
| Shielding | Metal shielded connectors |
| Insertion Cycles | ≥ 750 cycles |
| Characteristic | Value |
|---|---|
| NEXT (Near-End Crosstalk) | ≥ 44.3 dB @ 250 MHz |
| Insertion Loss | ≤ 19.8 dB @ 250 MHz |
| Return Loss | ≥ 12.0 dB @ 250 MHz |
| Delay Skew | ≤ 45 ns/100m |
-40°C to +75°C
(-40°F to +167°F)
IP67 Rated
Fully Waterproof
UV Resistant Jacket
10+ Years Outdoor Life
High Flexibility
-30°C Minimum Bending
Perfect for connecting outdoor WiFi extenders, garden offices, and backyard entertainment systems.
Ideal for connecting separate buildings on a campus or business park without conduit.
Weatherproof solution for IP cameras, motion sensors, and access control systems.
Temporary network infrastructure for construction trailers and site offices.
Public WiFi networks in parks, campgrounds, and outdoor event spaces.
Irrigation systems, soil sensors, and farm equipment connectivity in rural environments.
TIA/EIA-568-C.2
RoHS Compliant
UL Listed
IP67 Waterproof
UV Resistance
ISO/IEC 11801
